VSYS VCM-CE1546L Adjustable Single-Screen Ceiling TV Mount for 43"–86" Displays, 60 kg

Some rooms simply have nowhere to put a screen. Glass walls, structural columns, retail fixtures and open-plan floors all rule out a wall bracket — which is where the VSYS VCM-CE1546L Adjustable Single-Screen Ceiling TV Mount for 43"–86" Displays, 60 kg comes in. It hangs one large display from a telescopic pole that drops anywhere between 1090 mm and 1690 mm below the ceiling, so the same part number serves a standard office slab and a double-height atrium. The head rotates a full 360°, tilts down to -25° and offers plus or minus 3° of fine levelling, which is the difference between a screen that looks installed and one that looks hung. Cables run inside the pole, and the ceiling plate itself tilts to sit correctly on a flat or pitched structure.

Key Features

• Single-display ceiling mount - Designed to carry one screen from 43" to 86", not a back-to-back or side-by-side pair.
• 60 kg load rating - Cold-rolled steel construction strength tested to four times its rated load for permanent overhead installation.
• Telescopic pole, 1090 to 1690 mm - A 600 mm drop window, so one model covers office ceilings and high atriums alike.
• 360° rotation - Turn the display toward any part of an open-plan floor after installation, without touching the ceiling fixing.
• Tilt to -25° - A generous downward angle for screens hung well above eye level in terminals and retail halls.
• Plus or minus 3° levelling - Square the screen precisely against a ceiling line that is rarely perfectly true.
• Tiltable ceiling plate - Adapts to pitched and sloped structures instead of demanding a flat slab.
• In-pole cable management - Power and signal disappear inside the column for a finished, tamper-resistant look.
• VESA 200x200 to 600x400 mm - Covers the fixing patterns on most commercial displays in this size class, up to a 610x402 mm hole spread.
• 1.5 to 2.5 mm steel, powder-coated black - Corrosion-resistant and visually recessive against dark ceiling voids.

The value of a 360° rotation only becomes obvious after handover: a retail floor is re-merchandised, a boardroom table is turned, a queue line moves, and the screen follows without a single new fixing. Combined with the telescopic pole, that makes the VCM-CE1546L easy to standardise across a multi-site rollout, since one part number handles a mix of ceiling heights and a 43" to 86" spread of screen sizes. Integrators rely on the plus or minus 3° levelling to finish the job cleanly when the structure above is not square, and on the tiltable ceiling plate when the drawing says flat slab but the site says pitched roof. Picture it above a central boardroom table, or overhead in an airport concourse where every wall is glass.

Ideal for: airport terminals, open-plan retail floors, supermarkets, restaurants and central-table boardrooms across Dubai, Abu Dhabi, Sharjah and the GCC.
