Newline 86" Vega Pro Interactive Display
Newline 86" Vega Pro Interactive Display
The Newline 86" Vega Pro Interactive Display (SKU: TT-8624Z) is the ultimate solution for modern classrooms, boardrooms, and collaborative spaces. This cutting-edge interactive display boasts an impressive 86-inch 4K UHD touchscreen, delivering stunning clarity and vibrant visuals for any presentation or lesson. Enjoy seamless multi-touch technology that supports intuitive gestures, allowing multiple users to engage simultaneously. The Vega Pro Interactive Display comes equipped with advanced wireless connectivity and supports a wide array of collaboration tools to boost productivity. Its robust anti-glare glass ensures a clear view from every angle, while the integrated Android operating system provides access to countless apps and utilities. Experience smooth digital whiteboarding and effortless annotation features for dynamic meetings and lectures. With its sleek design and reliable performance, the Newline Vega Pro transforms any space into a hub of creativity and innovation. Choose the Newline 86" Vega Pro Interactive Display for a future-proof investment in interactive technology and superior user experiences.
Key Features
86-Inch 4K UHD Display - Delivers stunning visuals and exceptional detail for presentations and multimedia content.
Multi-Touch Technology - Supports up to 20 simultaneous touch points for collaborative engagement.
Integrated Android OS - Access apps, tools, and wireless sharing with built-in Android functionality.
Ultra-Smooth Writing Experience - Provides natural, responsive digital writing and annotation.
Anti-Glare Tempered Glass - Ensures visibility from any angle, reducing reflections in bright environments.
Wireless Screen Sharing - Effortlessly mirror devices without cables for seamless collaboration.
Powerful Built-In Speakers - Delivers rich, clear audio for engaging presentations and videos.
Flexible Mounting Options - Compatible with wall mounts and mobile stands for different room layouts.
Comprehensive Collaboration Tools - Includes whiteboarding, annotation, and file sharing features.
Secure User Management - Protects sensitive data with advanced security protocols and user profiles.
Plug-and-Play Connectivity - Multiple HDMI, USB, and network ports for easy integration with existing devices.
Elevate your workspace with the Newline 86" Vega Pro Interactive Display. Designed for seamless collaboration and outstanding performance, this interactive display is perfect for educational institutions and professional settings seeking the best in touchscreen technology.
| Name | Newline 86" Vega Pro Interactive Display |
| Screen Size | 86 inch |
| Built-in Camera | 4K |
| Built-In Microphones | 8 Microphone Array, 8 m pickup range |
| Sensors | Proximity |
| Wall Mount | 800 × 400 mm (VESA) |
| Power Consumption | 146 W |
| Power Standby | < 0.5 W |
| Product Dimensions | 1965 × 1184 × 95 mm |
| Product Weight | 59 kg |
| Wake-on-LAN | Yes |
| Blue-Light Filter | Yes |
| RAM | 8 GB |
| Storage | 128 GB |
| GPU | Mali Odin G52 × 8 |
| CPU | Arm Cortex-A73 × 4 + Cortex-A53 × 4 |
| OS Version | Android 13 |
| Touch Points | 40 Points Multi Touch |
| Touch Technology | Projected Capacitive Touch |
| Palm Rejection | Yes |
| Touch Accuracy | ± 1 mm |
| Surface Protection | Anti-Glare Smooth Glass |
| Ethernet (RJ45) | Gigabit LAN (RJ45) × 2 |
| Wi-Fi | Wi-Fi 6 |
| Bluetooth | Bluetooth 5.2 |
| Serial Port | RS232 × 1 |
| OPS PC Slot | Optional |
| USB Ports | USB 3.2 Type-A × 4, USB Type-C 3.0 × 1, USB 3.2 Type-A Android × 1 |
| Touch USB Ports | USB 3.2 Type-B (Touch) × 4 |
| Audio Out | Audio Line Out × 1 |
| Audio In | Microphone In × 1 |
| Type C in | Type-C (Powered 100 W) × 1, Type-C 3.0 (Powered 15 W) × 1 |
| DP 1.2 | Display Port 1.2 Input x 1 |
| Hdmi Output | HDMI Out 2.0 × 1 |
| Hdmi Input | HDMI In 2.1 × 3 |
| Speaker Output | 20 W × 2 + 15 W × 1 |
| Speaker Type | Built-in Speakers |
| Brightness | 450 cd/m² |
| Display Color | 10bit |
| Resolution | 3840 × 2160 |
| Viewing Angle | 178° (H) / 178° (V) |
| Backlight | Direct LED |
| Built-In Microphone | 8 Microphone Array, 8 m pickup range |
