MAXHUB 86 inch U4 Series Interactive Display – Model U8640
MAXHUB 86 inch U4 Series Interactive Display – Model U8640
The MAXHUB 86 inch U4 Series Interactive Display – Model U8640 is the ultimate solution for modern meeting rooms, educational environments, and collaborative workspaces. Featuring an impressive 86 inch 4K ultra HD touchscreen, this interactive display delivers crystal-clear visuals and seamless touch responsiveness for an engaging user experience. With advanced multi-touch technology, the MAXHUB U8640 supports up to 20-point touch, making group collaboration effortless. The integrated wireless screen sharing allows easy content sharing from any device, while the built-in Android operating system ensures intuitive operation. Enhance communication with the integrated camera and microphone array, perfect for remote meetings and video conferencing. The sleek, all-in-one design of the MAXHUB U4 Series complements any professional or educational setting. Transform how you present, teach, and collaborate with this feature-rich interactive flat panel. With robust connectivity options, anti-glare glass, and energy-efficient performance, the MAXHUB U8640 is engineered to boost productivity and engagement in any environment.
Key Features
86 Inch 4K UHD Display - Exceptional ultra-high-definition visuals for immersive presentations.
20-Point Multi-Touch - Supports multiple users for simultaneous collaboration and interactivity.
Integrated Camera & Microphone - Crystal-clear video and audio for seamless video conferencing.
Wireless Screen Sharing - Effortlessly share content from laptops, tablets, or smartphones.
Built-in Android OS - User-friendly interface with access to a range of apps and tools.
Anti-Glare Tempered Glass - Ensures clear viewing from any angle, even in brightly lit rooms.
All-in-One Design - Sleek, modern appearance with integrated speakers and ports.
Multiple Connectivity Options - Includes HDMI, USB, and LAN ports for versatile use.
Energy Efficient - Designed for low power consumption without compromising performance.
Easy Wall Mounting - Compatible with standard VESA mounts for flexible installation.
Collaborative Whiteboarding - Advanced annotation tools for brainstorming and idea sharing.
The MAXHUB U8640 sets a new standard in interactive display technology with its stunning 4K resolution, advanced touchscreen capabilities, and comprehensive collaboration features. Ideal for both business and education, this display empowers teams to interact, share, and innovate with ease.
| Name | MAXHUB 86 inch U4 Series Interactive Display – Model U8640 |
| Refresh Rate | 60 Hz |
| Screen Size | 86 inch |
| Built-in Camera | 50 MP |
| Built-In Microphones | 8-mic array, 0~12m pickup range |
| Accessories | Smart Pen: SP30B, Sensor Box: WL10C, WL20, Mobile Stand: ST33M, ST23B, EST09 |
| Power Consumption | 100 W |
| Power Standby | 0.5 W |
| Blue-Light Filter | Yes |
| RAM | 16 GB |
| Storage | 256 GB |
| NPU | 6 TOPS |
| GPU | Mali-G610 MP4 |
| CPU | A76 × 4 + A55 × 4 Octa-core, 2.4GHz |
| OS Version | Android 15 |
| Touch Points | 50 Points Multi Touch |
| Touch Technology | Infrared |
| Pen and Touch Differentiation | Yes |
| Palm Rejection | Yes |
| Touch Accuracy | ± 0.5 mm |
| Surface Protection | Non-glare 25% hazeEtched-AG Technology |
| Ethernet (RJ45) | RJ45 IN × 1, RJ45 OUT × 1 |
| Wi-Fi | Wi-Fi 6, 2.4G/5G |
| Bluetooth | Bluetooth 5.2 |
| Serial Port | RS232 × 1 |
| SD Card Slot | TF Card Port × 1 |
| USB Ports | USB 2.0 × 1, USB 3.0 × 4 |
| Touch USB Ports | Touch × 2 |
| Audio Out | Audio Out × 1 |
| Audio In | Audio In × 1 |
| Type C in | USB Type-C × 2 |
| DP 1.2 | DisplayPort Input × 1 |
| Hdmi Output | HDMI Out × 1 |
| Hdmi Input | HDMI In × 4 |
| Speaker Output | 2 × 8W + 2 × 18W (output); 2 × 12W + 2 × 25W (maximum) |
| Speaker Type | Built-in Speakers |
| Brightness | 500 cd/m² |
| Display Color | 10bit |
| Resolution | 3840 × 2160 |
| Viewing Angle | 178° (H) / 178° (V) |
| Backlight | DLED |
| Built-In Microphone | 8-mic array, 0~12m pickup range |
