iiyama ProLite 10-inch Touch Panel PC – TW1023ASC-B2P
- Ultra fine touch for faster interaction
- 4K UHD clarity for modern spaces
- Multiple connectivity options
The iiyama ProLite TW1023ASC-B2P is a 10.1-inch digital signage display featuring projective capacitive touch and Android 13. It supports 24/7 operation with PoE and VESA mounting, supplied by SmartScreens.ae across Dubai, Abu Dhabi, and Sharjah.
This 10.1-inch interactive display delivers a 1280 x 800 native resolution on an IPS panel with 450 cd/m² brightness. The edge-to-edge glass ensures durability in high-use environments. It operates on Android 13 with a Rockchip RK3568 processor, 4GB RAM, and 32GB storage for reliable performance.
Installation is simplified by IEEE802.3 at PoE support, providing power and data via a single cable. The unit includes a built-in microphone, 2x1.5W speakers, and HDMI mini output. It supports landscape, portrait, and face-up orientations with 75 x 75mm VESA mounting compatibility.
Key Features
- Touch & Display - 10.1-inch IPS panel with 1280 x 800 resolution and 10-point projective capacitive touch.
- Android System - Runs Android 13 with RK3568 CPU, 4GB DDR4 RAM, and 32GB eMMC storage.
- PoE Connectivity - Supports IEEE802.3 at PoE for combined power and network data over a single cable.
- Audio & Mic - Includes a built-in microphone and two 1.5W speakers for interactive audio applications.
- Mounting Options - Supports VESA 75 x 75mm mounting in landscape, portrait, or face-up orientations.
- Durability - Features 1.25mm edge-to-edge glass with 6H hardness for high-traffic retail or POS use.
- Operating Time - Designed for 24/7 non-stop operation with flicker-free technology to reduce eye strain.
The device is designed for continuous operation with flicker-free technology and a 25ms response time. It features 10-point touch input compatible with gloves and styluses. SmartScreens.ae provides quote-based pricing, TRN VAT invoicing, and professional installation services for UAE businesses and government entities.
Ideal for interactive POS terminals in Dubai retail stores, information kiosks in Abu Dhabi malls, and hospitality check-in points in Sharjah.
Request a quote: call +971 4 546 5041, message WhatsApp, or email info@procure.ae. SmartScreens.ae (part of Procure FZE), Dubai Silicon Oasis, UAE.
iiyama ProLite 10-inch Touch Panel PC – TW1023ASC-B2P specifications
- Colour
- black, matte
- In the Box
- quick start guide, safety guide, AC adapter, cable cover
- Audio In
- Mini jack x1
- Audio Out
- Speakers 2 x 1.5W
- Backlight
- IPS
- Bluetooth
- Bluetooth 5.2
- Brightness
- 450 cd/m²
- Built-in Camera
- Yes
- Processor
- Rockchip RK3568 Quad-core A55 × 4
- Colour Depth
- 16.7mln 8bit
- Ethernet (RJ45)
- x1 (PoE - IEEE802.3 at/Max. 30W)
- Graphics
- G52 MP2
- HDMI Output
- HDMI Out × 1
- Operating System
- Android 13
- Power Consumption
- 18W typical, 0.5W stand by
- Standby Power
- 0.5 W
- Product Dimensions
- 255 × 172 × 30.5 mm
- Product Weight
- 0.8 kg
- RAM
- 4 GB
- Resolution
- 1280 × 800
- Screen Size
- 10.1 inch
- SD Card Slot
- SD Card Slot × 1
- Shipping Dimensions
- 398 × 223 × 68 mm
- Speaker Output
- Speakers 2 × 1.5W
- Speaker Type
- Built-in Speakers
- Storage
- 32 GB
- Surface Protection
- 1.25mm
- Touch Points
- 10 (HID, only with supported OS)
- Touch Technology
- Capacitive
- USB Ports
- x4 (1 x 3.2 Gen1 (5Gbps, DC5V, 900mA), 2 x 2.0 (DC5V, 500mA), 1 x MICRO with OTG)
- Viewing Angle
- horizontal/vertical: 160°/160°, right/left: 80°/80°, up/down: 80°/80°
- VESA Mount
- 75 × 75 mm (VESA)
- Wi-Fi
- Wi-Fi IEEE802.11a/b/g/n/ac
- Shipping Weight
- 1.36kg
- Aspect Ratio
- 16:9
- Contrast Ratio
- 1000:1 with touch
- Controls
- Power, home, brightness +, brightness -, volume +, volume -
- Duty Cycle
- 24/7
- Input Voltage
- DC 12 V
- Orientation
- landscape, portrait, face-up
- Outputs
- HDMI x1 (mini HDMI, 1280x720 @60Hz)
- Panel Technology
- IPS
- Power Source
- external
- Response Time
- 25ms
- Microphone
- x1
- Certifications
- CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
- Connectivity Options
- USB
Frequently Asked Questions
Can I purchase the iiyama ProLite TW1023ASC-B2P in the UAE?
Yes, SmartScreens.ae supplies the iiyama ProLite TW1023ASC-B2P across the UAE. We provide quotation-based pricing with best-price guarantees, TRN VAT invoicing for government and enterprise buyers, and professional installation services in Dubai, Abu Dhabi, and Sharjah.
Does this model support Power over Ethernet?
Yes, the TW1023ASC-B2P includes an RJ45 LAN port supporting IEEE802.3 at PoE. This allows you to deliver both data connectivity and 30W of power through a single cable, simplifying installation in retail or office environments.
Is a free demonstration available before purchase?
Yes, SmartScreens.ae offers free on-site or virtual demonstrations. Our team can show you the touch responsiveness, Android 13 interface, and PoE setup options to help you evaluate the display for your specific UAE business needs.
What is the touch technology used?
The display uses projective capacitive touch technology. It supports 10 simultaneous touch points via USB and is compatible with finger, latex glove, and capacitive stylus inputs, making it suitable for various interactive applications.
What are the operating system specifications?
The unit runs Android 13, powered by a Rockchip RK3568 Quad-core A55 CPU and G52 MP2 GPU. It includes 4GB DDR4 memory and 32GB eMMC storage, supporting Wi-Fi 5 and Bluetooth 5.2 for wireless connectivity.
Does the product come with installation services?
Yes, SmartScreens.ae provides professional installation services across the UAE. This includes mounting in landscape, portrait, or face-up orientations, connecting PoE or HDMI inputs, and ensuring the device is ready for immediate interactive use.
