Biamp Parlé TTM-XEX Tabletop Microphone – 920-00511

The Biamp Parlé TTM-XEX (920-00511) is a white tabletop expansion microphone designed for video conferencing rooms. Featuring a 16-element digital array and Beamtracking technology, it captures voices across four 90-degree zones. SmartScreens.ae supplies this TAA-compliant unit with quotation-based pricing and UAE-wide support.

The Parlé TTM-XEX expands conferencing audio coverage using a 16-element digital array that actively tracks and mixes voices. Its Beamtracking technology automatically focuses on active speakers without manual lobe aiming or room mapping. The unit covers 360 degrees through four 90-degree zones, ensuring balanced pickup for natural conversations in meeting spaces.

Installation is streamlined via a single CAT5 cable that delivers both signal and power, eliminating the need for separate power adapters. The included network box houses built-in DSP for precise Beamtracking processing, requiring only one AEC channel per device. An RJ-45 connection allows daisy-chaining multiple TTM-XEX units to scale coverage across larger rooms.

Key Features

• Beamtracking Technology - Actively tracks and intelligently mixes voices across the room to ensure every participant is heard clearly.
• 360° Pickup Coverage - Four 90-degree zones provide complete room coverage for natural, balanced audio capture.
• Built-in DSP Processing - Integrated digital signal processing in the network box ensures precise Beamtracking without external hardware.
• Single CAT5 Connection - One cable provides both power and signal for simplified installation and reduced cabling complexity.
• TAA Compliant - Meets US Trade Agreement Act requirements, suitable for government and enterprise procurement in the UAE.
• Scalable Expansion - RJ-45 port supports daisy-chaining additional TTM-XEX units to expand system coverage as needed.

Audio performance is rated from 150 Hz to 16 kHz with a 90 dB dynamic range and a maximum SPL of 109 dB. The white 231 g unit operates between 0 to 40 °C and includes an LED mute indicator for status feedback. It is US Trade Agreement Act (TAA) compliant and backed by a 5-year warranty for long-term reliability.

Ideal for: Meeting rooms in Dubai, Abu Dhabi, and Sharjah where IT managers need to extend audio coverage without complex calibration.

Request a quote: call +971 4 546 5041, message WhatsApp, or email info@procure.ae. SmartScreens.ae (part of Procure FZE), Dubai Silicon Oasis, UAE.

Biamp Parlé TTM-XEX Tabletop Microphone – 920-00511 specifications

Colour

White

Operating Temperature

0 to 40 °C

Product Weight

231 g (0.5 lbs)

Warranty

5 years

Model

Parlé TTM-XEX

Product Type

Tabletop Expansion Microphone

Key Features

Beamtracking, 360° pickup, built-in DSP in network box, one AEC channel, single CAT5 connection, RJ-45 expansion, LED mute indicator

Dynamic Range

90 dB, A-weighted (THD+N < 10%)

Frequency Response

150 Hz to 16 kHz (±3 dB)

Max SPL

109 dB (at 0.5% THD)

Polar Pattern

Beamtracking, four 90° zones (360° coverage)

Microphone

16-element digital array

Certifications

TAA compliant

Connectivity Options

RJ-45, up to 10 m (33 ft) from DSP host device
